Short Description

The Circlip Pliers 1444-13 (Bent Nose) is a massive, industrial-grade precision tool featuring a 90-degree angled tip, specifically designed for the high-torque installation and removal of extra-large external circlips on shafts in obstructed or deep-seated industrial environments.

Long Description

Forged from premium 5Cr13 spring steel, the 1444-13 model is built to withstand the extreme mechanical stress required to expand large-scale industrial retaining rings. Its extended 310-mm profile provides maximum leverage, allowing operators to manage high-tension external clips with significantly reduced effort. The 90-degree bent nose design allows for superior visibility and access when working around obstacles or within recessed machinery where straight-nose pliers cannot reach.

The tool is finished with a professional black nitride coating for superior resistance to rust and surface wear in harsh environments. Featuring a heavy-duty return spring and ergonomic anti-slip rubberized handles, these pliers ensure that extra-large external circlips remain securely locked on the 3.2-mm precision-ground tips during expansion, making it a critical tool for heavy automotive, marine, and power plant maintenance.

Why Choose This Product?

Choose the 1444-13 for its unmatched 310-mm reach and specialized angled accessibility for external fasteners. It is specifically designed for professionals who manage external snap rings up to 165 mm in diameter in awkward or cramped orientations. Its hardened, corrosion-resistant frame and precision-machined tips ensure maximum stability, preventing dangerous slips and improving overall efficiency in heavy industrial applications.

Special Technical Specifications

• Material: 5Cr13 spring steel, 30H tempered, precision-ground tips
• Length: 310 mm
• Weight: 490 g
• Tip Angle: 90-degree bent nose
• Tip Diameter: 3.2 mm
• Circlip Capacity: 85 mm to 165 mm (External)
• Coating: Black nitride, anti-wear, anti-corrosion

Key Features

• 90-degree angled nose for superior accessibility to obstructed extra-large shafts
• Extended 310-mm design for maximum leverage and high-torque expansion
• Precision-machined 3.2-mm tips for a secure, non-slip grip on heavy-duty circlips
• Ergonomic, rubberized handle for improved comfort and high-leverage control

Applications

• Heavy industrial maintenance – managing large retaining rings on turbine and motor shafts
• Marine and Shipbuilding – installing external snap rings on large-scale propeller shafts
• Mining and Heavy Construction – servicing external clips on massive hydraulic components
• Railway and Locomotive repair – precise placement of fasteners in obstructed axle assemblies

Maintenance Instructions

• Apply a thin layer of light machine oil to the pivot and tips after each use to prevent rust
• Periodically check the heavy-duty return spring for smooth and consistent operation
• Store in a dry, cool place to maintain the integrity of the anti-corrosion coating
